Crimp Housing 4-Pole 3,96mm
Varenummer:
104-090
Varekode:
NSG396M-4
Vægt:
0 g
Lagerstatus:
Ikke på lager
Gruppe: F1444
MPE GARRY Nylon Crimp Connectors
Series: NSG396M, NSL396M
Pitch: 3,96mm
MPE GARRY Nylon Crimp Connectors
Series: NSG396M, NSL396M
Pitch: 3,96mm
| NSG396M_ |
| Nylon Crimp Housing |
 |
| Features |
| • For easy manufacturing of multipolar connections |
|
| Technical Specifications |
| |
| Insulation Shell: | Nylon 66, UL94V-0 |
| Rated Voltage: | 7,0A |
| Rated Current: | 250VRMS/V DC |
| Dielectric Strength (1min.): | 1500VRMS |
| Temperature Range: | -25...+85°C |
| |
| Dimensions |
| |||||||
| Pole | 02 | 03 | 04 | 05 | 06 | 08 | 09 |
| A [mm] | 8,02 | 11,98 | 15,94 | 19,9 | 23,86 | 31,78 | 35,74 |
| B [mm] | 3,96 | 7,92 | 11,88 | 15,84 | 19,8 | 27,72 | 31,68 |
| |||||||
| NSK396M-0 |
| Crimp Contacts |
|
| Eigenschaften |
| • For use with connector housing NSG396M-_ • Suitable for cables AWG18...AWG22 • Contact brass, tin-plated • Form of delivery: taped |
|
| NSL396M_ |
| PCB Header |
|
| Features |
| • NSL396M-_G: straight version • NSL396M-_W: angled version |
|
| Technical Specifications |
| |
| Insulation Shell: | Nylon 66, UL94V-0 |
| Contacts: | Copper Alloy |
| Contact Surface: | Tinned |
| Rated Current: | 5,0A |
| Rated Voltage: | 250VRMS/V DC |
| Dielectric Strength (1min.): | 1500V AC |
| Temperature Range: | -25...+85°C |
| |
| Dimensions |
| Pole | 02 | 03 | 04 | 05 | 06 | 08 |
| A [mm] | 7,92 | 11,88 | 15,84 | 19,8 | 23,76 | 31,68 |
| B [mm] | 3,96 | 7,92 | 11,88 | 15,84 | 19,8 | 27,72 |
| ||||||
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 100 pieces |
|
| Manufacturer |
 |
| http://www.mpegarry.de |
|
