Relay SPDT 10A 6V 100R 36.11.9.006.4011
Varenummer:
103-899
Varekode:
F36119-006A
Vægt:
20 g
Lagerstatus:
Ikke på lager
| Features |
| • Smaller size • Wash tight enclosure • Coil 360mV • Relays protection class RTIII |
 |
| Technical Specifications |
|
|||||||||||||||||||||||||||||
| Contact: | SPDT | Contact Material: | AgSnO2 | Rated Current: | 10A | Max. Switching Current: | 15A | Max. Switching Voltage: | 250V AC | Max. Switching Power: | 2500VA | Operate/Release Time: | 9/3ms | Testing Voltage | Coil/Contact: | 4000V AC | Opening Contact: | 1000V AC | Lifetime | Mechanical: | 10x106 Operations | Electrical: | 10x104 Operations | Operating Temperature: | -40...+85°C | ||||
|
|||||||||||||||||||||||||||||
| Coil Data |
| Part Nr. | UN | Umin. | Umax. | IN | RN | � | [V DC] | [V] | [V] | [mA] | [W] | F36119-003A | 3 | 2,2 | 4,5 | 120 | 25 | F36119-005A | 5 | 3,7 | 7,5 | 72 | 70 | F36119-006A | 6 | 4,5 | 9 | 60 | 100 | F36119-009A | 9 | 6,7 | 13,5 | 40 | 225 | F36119-012A | 12 | 9 | 18 | 30 | 400 | F36119-024A | 24 | 18 | 36 | 15 | 1600 | F36119-048A | 48 | 36 | 72 | 7,5 | 6400 | ||||||
| UN = Rated Voltage, Umin. = Minimum Operating Voltage, Umax. = Maximum Operating Voltage, IN = Rated Current, RN = Coil Resistance; All Specifications Measured at 20°C | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Approvals |
  |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces |
|
| Manufacturer |
 |
| http://www.finder.de |
|
Stregkode:
103899
Intern reference:
103899
Varekode:
F36119-006A
