Relay SPDT 8A 5V 115R M15FSH001805VDC

Varenummer:
103-872
Varekode:
M15F05A
Vægt:
20 g
Lagerstatus:
Lager: 308 stk.

kr 34,20 34.2 DKK kr 34,20 Inklusiv moms

kr 34,20 Inklusiv moms

Anmod os om en pris

v/10
Kr. 32,06
v/25
Kr. 26,72
v/100
Kr. 16,38
v/300
Kr. 12,50

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/59628/image_1920?unique=649e686 https://elektroniklavpris.odoo.com/web/image/product.template/59628/image_1920?unique=649e686



Features

• SPDT
• Sealed according to IP 67 standard
• Very sensitive: operating response only 100mW
• Insulated 4kV/8mm
• High contact force
• Very low contact noise
• Switching capability 8A/250V AC
• Height 15mm, PCB mounting
Technical Specifications

Insulation Resistance (500V DC):
 2x107MW
Test Voltage
Open Contact, (1 Min.):
 1000V AC
Coil/Contact/Ground:
 4000V AC
Operating Temperature:
 -40...+70°C
Operate Time, Max. (1,35xVmin., Without Bounce Time):
 9ms
Release Time, Max. (Without Bounce Time):
 3ms
Vibration Resistance (10...100Hz):
 10G
Weight:
 10g
Working Class:
 C/Continuous
Contact Data

Configuration:
 SPDT
Contact Material:
 AgSnO2
Rated Current:
 8A
Rated Voltage:
 250V AC
Switching Power, (Ohmic Load) Max.:
 2000VA
Switching Voltage, Max. (VDE0435):
 380V AC
Switching Current, Max.:
 10A
Operating Life
Mechanical (20000 Operations/h):
 30x106 Operations
Electrical (8A/250V AC):
 100 000 Operations
Coil Data

Coil Type:
 Monostable
Nominal Voltage:
 See Table
Nominal Coil Power:
 225mW
Part Nr.
 UN
 Umin.
 Umax.
 RN
  [V DC]
 [V DC]
 [V DC]
 [W]
M15F05A 5
 3,4
 9,0
 115
M15F12A 12
 8
 21,2
 640
M15F24A 24
 16
 42,2
 2550
M15M24A 24
 16
 42,2
 2550
UN = Rated Voltage, Umin. = Minimum Operating Voltage at 20°C, Umax. = Maximum Operating Voltage at 40°C, RN = Winding Resistance, Rated Value at 20°C, ±10% Tolerance

Approvals


Additional Products
We can also supply on request (minimum order quantity: 500 pieces, delivery time 4 to 8 weeks):
• relays with rated voltages of 1,5 to 8V, 18V, 48V and 110V
• relays with gold-plated silver contacts AgNi
• relays with 5,0mm pitch (M15B_)


Manufacturer
Feme
